Simple Integration of Three-phase Shunt Active Power Filter and Photovoltaic Generation System with Fibonacci-Search-Based MPPT

This paper proposes a three-phase four wire current-controlled Voltage Source Inverter (CC-VSI) for both harmonic mitigation and PV energy extraction. For harmonic mitigation, the CC-VSI works as a grid current controlling shunt active power filter. Then, the PV array is coupled to the DC bus of the CC-VSI. The MPPT controller employs the Fibonacci search method. The output of MPPT controller is a DC voltage that determines the DC-bus voltage according to the PV maximum power. From computer simulation, the CC-VSI can effectively compensate for harmonics as well as deliver PV power to the grid.
